5. SPECIFICATION
5-7
5.2 Memory Space
0
Conventional memory
500
(DOS application area)
A0000
Video RAM window
C0000
Video BIOS (*1)
D0000
Extended BIOS space (*2)
E0000
System BIOS
(Flash ROM)
100000
(1MB)
Main memory
DF20 0000
Memory-mapped I/O
1 0000 0000
4 1FFF FFFF
Main memory
(Up to16.5GB)
(*1) The size of the video BIOS may change in future versions.
(*2) The extended BIOS space is a narrow space between D0000 and DFFFF and may already be in use by
other devices. In addition, the size of the BIOS of standard built-in adapters may change in future
versions. It is advisable that you do not use the extended BIOS space if at all possible when you design
a new device. If you do, a contention may occur between devices and malfunctions of the devices may
result.
Space available for real mode.
