2. OPERATION
2-10
2.8 Setting Up the LAN Interface
This equipment has two built-in 1000BASE-T/100BASE-TX/10BASE-T LAN ports. For
information about the location of the LAN port connector (1000BASE-T/100BASE-
TX/10BASE-T), see “1.5 Name and Function of Each Part”.
● Automatic recognition of the network transfer speed or transfer mode
The LAN port has an auto-negotiation function to automatically recognize the network
transfer speed or transfer mode. For normal use, enable the auto-negotiation function.
(Especially when you use the WOL function. If the speed is fixed to 1000Mbps (auto-
negotiation), the WOL function cannot be used.)
If there is a compatibility issue with the connected hub, the auto-negotiation function may
not work properly and that may affect the communication with other terminals.
If the auto-negotiation function does not work properly, configure the LAN interface as
follows.
Specification of
the hub
Specification of the LAN setting (*)
Speed Duplex
10 Mbps / Half-
duplex
10 Mbps Half Duplex
10 Mbps / Full-
duplex
10 Mbps Full Duplex
100 Mbps / Half-
duplex
100 Mbps Half Duplex
100 Mbps / Full-
duplex
100 Mbps Full Duplex
1000 Mbps 1000 Mbps (1.0 Gbps)
Auto Negotiation or
Full Duplex
(*) How the setting is displayed is different depending on the OS and the
LAN port (including the optional LAN adapter) in use.
< NOTE >
・ For information about the precautions for the network, see “PRECAUTIONS 2.
NETWORK”.
