2. OPERATION
2-7
2.7 Controlling the Power Using the LAN
The power for this equipment can be turned on from a remote device by way of the LAN.
This section explains WOL (Wake ON LAN), which is used for turning on the power for
the equipment through the LAN. When the power is turned on by using WOL, the equipment
is started by sending a Magic Packet™ frame to the LAN interface when the standby lamp
(STBY) is on.
In the initial factory settings, this function is disabled. If you want to use this function,
follow steps 1 through 3 described in “2.7.1 Enabling the WOL (Wake ON LAN) function”
to enable the WOL function and then follow the steps below.
2.7.1 Enabling the WOL (Wake ON LAN) function
By following the procedure below, you can set up whether to start WOL when a Magic
Packet™ frame is received. In the initial factory settings, the WOL function is disabled.
(The display image assumes Windows® 10 IoT but it is similar under other OS.)
1. Execute steps 1 though 5 in “● Setting up the network transfer speed” in “2.8 Setting
Up the LAN Interface”.
2. Click the Power Management tab. If you want to enable WOL, select the Wake on
Magic Packet from power off state check box under Wake on LAN :.
3. Click OK and restart the system.
< NOTE >
・ For information about the precautions for the network, see “PRECAUTIONS 2.
NETWORK”.
