1. GETTING STARTED
1-6
(2) Rear view
(*1) If a display unit connected with DisplayPort is turned off, the display cannot be detected.
(*2) PCI Express x16 connectors is used but the internal connection is equivalent to PCI Express x4.
Figure 1-2 Name of Each Part (Rear View)
AC inlet
USB3.0 port
（4 port）
Serial port
（COM1）
Audio port
Upper
：
LINE IN
Lower
：
LINE OUT
DVI-I port
DVI-D port
1
Slot1：PCI
ACT/LINK lamp
Communication speed lamp
LAN port:
1000BASE-T/100BASE-TX/10BASE-T
Extension slots
DisplayPort(*1)
2
3
Slot2：PCI Express x4 (*2)
Slot3：PCI Express x16
・Left side ：LAN1
・Right side：LAN2
