Chapter 7. Auxiliary Functions
7-36
Detailed explanation of Classification No.2 (Table 2)
● The conditions of Print data are described in Table 3, which can be used when a part of setting is
corrected.
Table 3. Conditions with which display color of Message name changes to Brown on "Select message"
screen
No.
Item
Conditions and corrections
1
Ink drop use (High-speed print)
There are some Ink drop use rates which are NOT available on
the lower model. "Ink drop use" of Print data shall be set to the
configurable value. Set to [HM] for "High-speed print".
[NOTE]
● After executing Select message, correct and confirm the Print data. And then please overwrite and use it
for printing. (Display color of Message name on "Select message" screen changes from Brown to Black.)
Detailed explanation of Classification No.3 (Table 2)
● The conditions of Print data which can NOT be used are described in Table 4 below.
Table 4. Conditions with which display color of Message name changes to Red on "Select message" screen
No.
Item
Conditions
1
Printing columns
Max Printing columns of the lower model < Printing columns of Print
data
2
Calendar items
Max Calendar items of the lower model < Calendar items of Print data
3
Replacement items
Max Replacement items of the lower model < Number of Substitution
rules of Print data
4
Count items
Max Count items of the lower model < Count items of Print data
5
Bar code/ 2D code print
Bar code is set, which CANNOT be set on the lower model. 2D code
print is set, which CANNOT be set on the lower model.
6
Shift code Time count
Shift code is set, which CANNOT be set on the lower model. Time
count is set, which CANNOT be set on the lower model.
