ATTACHMENT
Allowable Weight Limits of Installed Attachment
x
When an attachment other than the standard bucket is
installed on the machine, the machine stability will be
different. If a heavy attachment is used, not only will con-
trollability be affected but also machine stability will be
reduced, possibly causing safety hazard.
x
Before installing attachments such as hydraulic breaker,
crusher (concrete crusher), or pulverizer, take machine
controllability into account when selecting the weight of
the attachment by referring to the table below.
x
Breaker operation speed is faster than crusher operation
so that the recommended breaker max. weights are re-
duced more than those of the crushers.
x
The weight is not the only factor to be considered when
selecting a breaker. Select proper manufacturers’
breaker models while referring to the table on the next
page.
x
Avoid installing an attachment with a long overall length.
Damage to the front attachment may result.
x
When an attachment of the max. weight is installed, al-
ways operate the attachment over the front or rear side
of the machine. In addition, avoid operating the attach-
ment at the maximum reach.
x
Crushers are heavier than breakers. Slowly move the
control lever when operating a crusher.
Unit: kg (lb)
Base Machine Breaker Crusher/Pulverizer
Specification
Model Arm Std. Weight Max. Weight Std. Weight Max. Weight
Std. 800 (1760) 900 (1980) 1000 (2200) 1150 (2540)
Demolition Type ZAXIS80LCK
Long 650 (1430) 700 (1540) 750 (1650) 900 (1980)
ZAXIS70 Std. 650 (1430) 700 (1540) 750 (1650) 900 (1980)
ZAXIS70LC Std. 700 (1540) 750 (1650) 850 (1870) 1000 (2200)
ZAXIS85US Std. 700 (1540) 750 (1650) 800 (1760) 950 (2090)
ZAXIS80SB Std. 550 (1210) 600 (1320) 650 (1430) 750 (1650)
Standard Type
ZAXIS80SBLC Std. 600 (1320) 650 (1430) 700 (1540) 850 (1870)
