SHOE TYPES AND APPLICATIONS (with Blade)
ZAXIS85US(with Blade)
Shoe Width
450 mm(18")
Grouser
Shoe
600 mm(24")
Grouser
Shoe
450 mm(18")
Flat Shoe
450 mm(18")
Pad Crawler
Shoe
450 mm(18")
Rubber
Crawler
Shoe
Application
For Ordinary
Ground
(Standard)
For Weak
Footing
(Option)
For Paved
Road
(Option)
For Paved
Road
(Option)
For Paved
Road
(Option)
Operating Weight kg (lb) 7600(16760) 7800(17200) 7800(17200) 7700(16980) 7550(16650)
Basic Machine Weight
kg (lb)
6300(13890) 6500(14330) 6500(14330) 6400(14110) 6250(13780)
Cab Height mm (ft·in) 2690(8’10”) 2690(8’10”) 2700(8’10”) 2720(8’11”) 2700(8’10”)
Minimum Ground
Clearance mm (ft·in)

360 (1’2”)

360 (1’2”) 390 (1’3”) 410 (1’4”) 390 (1’3”)
Undercarriage mm (ft·in)
Length
2920 (9’7”) 2920 (9’7”) 2940 (9’7”) 2970 (9’9”) 2940 (9’8”)
Undercarriage Width
mm (ft·in)
2320 (7’7”) 2470 (8’1”) 2320 (7’7”) 2320 (7’7”) 2320 (7’7”)
Ground Pressure
33 kPa
(0.34 kgf/cm
2
)
(4.8 psi)
25 kPa
(0.26 kgf/cm
2
)
(3.8 psi)
33 kPa
(0.34 kgf/cm
2
)
(4.8 psi)
33 kPa
(0.34 kgf/cm
2
)
(4.8 psi)
33 kPa
(0.34 kgf/cm
2
)
(4.8 psi)
NOTE:
•
The specifications for the front-end attachment is for 1.62 m arm with PCSA 0.28 m
3
bucket.
•
600 mm grouser shoe and 450 mm flat shoe should not be used on gravel or rocky ground.
•

The dimensions do not include the height of the shoe lug.
•
The Pad Crawler and Rubber Crawler are designed for using on paved surfaces. Do not use the Pad
Crawler and Rubber Crawler on gravel or rocky ground.
