Hitachi ZAXIS 70 - Key Switch; Horn Switch

OPERATOR'S STATION
1-17
KEY SWITCH
1- OFF (Engine Off)
2- ACC (Horn, Radio etc.)
3- ON (Engine On)
4- START (Engine Start)
HORN SWITCH
Horn switch (6) is provided on the top of the left control
lever. The horn continuously sounds as long as the switch
is pressed.
M178-01-049
M1GF-01-004
6
4
3
2
1
