OPERATOR'S STATION
1-34
DEFROSTER OPERATION
Press mode switch (6) (either the front or front/rear
vent mode
switch). Set temperature control switch (8)
to the heat operation position. Press fresh air mode switch
(7).
Press blower switch (9). Warm air will blow out from the
front or front/ rear vents.
Adjust air flow direction from front vent (1) and defroster
vent (3) by controlling the louver direction.
Use temperature control switch (8) and blower switch (9) to
adjust air temperature in the cab.
M178-01-072
M1CC-01-017
6
7
8
9
1
3
