STORAGE
10-3
INSTALLING VANDAL-PROOF COVERS
1. Location of each vandal-proof covers to be installed
are shown.
2. In each section, install covers in order of the num-
bering.
3. Lock covers in each section when finished the instal-
lation.
NOTE: In case the sunshade is installed on the top of
the cab, remove the cover (2) and (3) shown
below from cab front (1). Then, install cover (1).
M1CD-10-001
