MAINTENANCE
7-68
Remove the Travel Levers
The travel levers may be removed if desired.
1. Park the machine on a level surface.
2. Lower the bucket to the ground.
3. Turn the auto-idle switch off.
4. Turn the key switch OFF. Remove the key.
5. Pull the pilot control shut-off lever to the LOCK
position.
6. Remove bolts (1) and (2) to remove levers (3) and (4)
from brackets.
NOTE: Wrench size 17 mm
Tightening torque 50 N
x
m (5.1 kgf
x
m, 37 lbf
x
ft)
Check and Replace Seat Belt
Check --- daily
Replace --- every 3 years
Always maintain the seat belt in a functional condition and
replace when necessary to ensure proper performance.
Prior to operating the machine, thoroughly examine belt (5),
buckle (6) and attaching hardware (7). If any item is dam-
aged or materially worn, replace the seat belt or compo-
nent before operating the machine.
We recommend that the seat belt be replaced every three
years regardless of its apparent condition.
Check Windshield Washer Fluid Level
--- as required.
Check fluid in windshield washer tank (8).
If the fluid level is low, remove cap (9) and add fluid via the
opening.
During winter season, use all season windshield washer
which will not freeze.
M178-07-077
M1CC-07-036
M1CD-07-025
M1CG-07-016
4
7
3
1
5
2
6
7
7
9
8
9
8
ZAXIS70, 70LC, 80SB, 80SBLC, 80LCK
ZAXIS85US
