Hitachi ZAXIS 70 - Working Ranges (Offset)

OPTIONAL ATTACHMENTS AND DEVICES
13-16
WORKING RANGES
(Offset)
ZAXIS70, 70LC
M1CD-12-005
Working Ranges
Off-Set Distance (0 mm)
Max. Off-Set Distance(1160 mm
(3'10"))
Category
Item
mm ft·in mm ft·in
A : Maximum Digging Reach
6320
20
'
9”
5875
19
'
3”
B : Maximum Digging Depth
4160
13
'
8”
3710
12
'
2”
C : Maximum Cutting Height
7130
23
'
5”
6775 22
'
3”
D : Maximum Dumping Height
5050
16
'
7”
4700 15
'
5”
E : Transport Height
*1
2810
9
'
3”
2815 9
'
3”
F : Overall Transport Length
6200
20
'
4”
5780 18
'
12”
F' : Overall Transport Length
(with Blade)
6420
21
'
1”
6000 19
'
8”
G : Minimum Swing Radius
2100
6
'
11”
L: 2100
R 2260
6
'
11”
7
'
5”
H : Front-End Attachment Height
at Min. Swing Radius
5620
18
'
5”
5620 18
'
5”
NOTE: *
1
The dimensions include the height of the shoe lug.
D
G
E
H
Ａ
F, F’
B
C
M1CC-12-010
1160
(3'10")
1160
(3'10")
