MAINTENANCE
7-48
Clean Feed Pump Strainer
--- every 1 000 hours,
Cleaning Procedure
1. Remove fuel inlet side joint bolt (3) from water sepa-
rator (2). Remove plug (5) and strainer (4) out of joint
bolt (3). Wash them in a cleaning oil.
2. After cleaning, install strainer (4) and plug (5) into
joint bolt (3). Tighten joint bolt (3) to the water sepa-
rator.
Joint Bolt Tightening Torque: 20 to 25 N·m (2.0 to 2.5
kgf·m, 15 to 18 lbf·ft)
Bleed Air from Fuel System
After cleaning the feed pump strainer, bleed air trapped
in the fuel system. (Refer to the description on “Bleed Air
from Fuel System” in (3).
M1CD-01-017
M1CG-07-017
M178-07-102
4
3
2
5 3
ZAXIS70, 70LC, 80SB 80SBLC, 80LCK
2
3
ZAXIS85US
To Next Page
