Is used to operate the lift arm and the bucket.
(C) Float: The lift arm free falls and can be moved as loads are
applied.
(B) Lift arm Lower
(N) Hold: The lift arm is stopped and held in that position.
(A) Lift arm Raise
(F) Detent: The lift arm is held in the raised position.
(G) Detent: When the lever is moved from the bucket dump
position to the bucket tilt position, the lever is held in
that position.
(D) Bucket Tilt
(N) Hold
(E) Bucket Dump
