1-38
When accelerator pedal (3) is stepped on, the engine speed
increases. When released, the engine speed decreases.
By operating clutch cut position switch (4), functions of right
and left brake pedals (1 and 2) can be changed to the service
brake or the inching brake.
(In case clutch cut position switch (4) is turned to the S, N, or
D position.)
Brake pedals (1 and 2) function as an inching brake. Use to
stop the machine in the specified position to engage the
machine in loading/unloading work.
(In case clutch cut position switch (4) is turned to the OFF
position.)
Brake pedals (1 and 2) function as a normal brake. Before
ascending or descending slopes, turn clutch cut position
switch (4) OFF.
Before operating the machine, adjust the steering column
height and inclination so as to match the operator’s physical
constitution. Press lever (5) to set the steering column height
and inclination to the desired position. Pull lever (5) to secure
the steering column in position and check that the steering
column is correctly secured.
M4GB-01-004
M4GB-01-046
M4GB-01-051
M4GB-01-005
