7-10
When opening side cover (1), pull latch (3) upward.
When opening side cover (4), after opening side cover (1),
lower open/close lever (5) located at the rear of the ma
-
chine.
NOTE: When required to inspect the machine for a long time
with the side cover kept open, lock the side cover using
the locking rod (6) provided inside the side cover.
Side cover (4) has a holding groove. Engage the hold
-
ing rod in the holding groove beforehand.
M4GB-01-141
M4GB-01-142
M4GF-07-001
M4GB-01-143
ZW180
ZW220, 250, 310
To Next Page
