Hitachi ZW310 - 7- Armrest Adjustment; 8- Reclining Angle Adjustment


1-66

The armrest is a movable type. Keep the armrest in the up
-
right position unless change is required.

The reclining angle can be adjusted by pulling up reclining
adjusting lever (8). The reclining angle can be adjusted up
to 10° forward and 34° backward by 2° intervals respectively.
After moving the reclining angle to the desired position,
return the reclining angle adjusting lever to the original po
-
sition. Check that the reclining angle is locked in the desired
position.
M4GB-01-104

