7-8
M4GB-01-085
M4GB-01-050
UNLOCK LOCK
M4GB-01-154
M4GB-01-004
Unless specially specified, park the machine by following the
procedures below before beginning the inspection and/or
maintenance work.
1. Park the machine on a solid level surface.
2. Lower the working tools such as the bucket to the
ground.
3. Turn optional rid control switch (1) OFF.
4. Place forward / reverse lever (6) to neutral and apply neu
-
tral lock (5).
5. Apply the parking brake (Turn parking brake (7) ON.)
6. Wedge the tires.
7. Turn the key switch OFF to stop the engine. Remove the
key from the switch. In case inspection and/or mainte
-
nance must be performed with the engine kept running,
use an observer.
8. Be sure to place front control lever (4) lock to the LOCK
position (3).
9. Start working only after putting an “UNDER INSPECTION/
MAINTENANCE” tag in a highly visible place such as on
the cab door or the control lever.
To Next Page
