1-9
If the engine coolant temperature increases to the abnormally
high range, the red indicator will light, the stop indicator will
flash, and the alarm buzzer will sound. Stop machine operation
and reduce the engine speed to the slow idle range to cool the
coolant temperature.
If the engine oil pressure becomes low, the low engine oil pres
-
sure indicator will light, the stop indicator will flash, and the
alarm buzzer will sound. Immediately stop machine operation
and stop the engine. Inspect the engine oil pressure system
and the oil level for any abnormality.
NOTE: Cold oil temperature or operating on a steep slope may
also cause the indicator to light.
If the fuel filter is clogged, the fuel filter restriction indicator
will light.
This indicator is not equipped on this machine.
M4GB-01-020
M4GB-01-021
M4GF-01-002
M4GB-01-023
