1-56
NOTE: When forward/reverse switch (23) is activated on for-
ward/reverse selector switch (5) comes ON.
3. Press the F or R position on forward/reverse switch (23).
NOTE: If forward/reverse lever (22) is placed in the F or R posi
-
tion when forward/reverse switch (23) is in use, for-
ward/reverse switch (23) will become inoperable. (Op-
eration by the forward/reverse selector lever has the
most priority.) When required to use forward/reverse
switch (23) again, repeat step 2.
Forward / reverse selector switch (5) activates forward / reverse
switch (23) located on the front control lever side. When for-
ward/reverse selector switch (5) is ON, press the F or R position
on forward/reverse switch (23) to drive the machine forward or
in reverse.
1. Turn the parking brake OFF.
2. Place forward/reverse lever (22) and forward/reverse
switch (23) in the N position. Then, turn forward/reverse
selector switch (5) ON. (When forward/reverse selector
switch (23) is operable, indicator (24) on monitor panel
lights.)
M4GB-01-050
M4GB-01-044
M4GB-01-064
M4GB-01-042
M4GF-01-001
M4GB-01-083
Finger Type
Multi-function Type
