1- Cutting Edge
2- Bucket
3- Bell Crank
4- Bucket Cylinder
5- Head Light/Turn Signal / Hazard Light /
Clearance Light
6- Outside Rear View Mirror
7- Front Work Light
8- ROPS Cab
9- Rear Fender
10- Articulation Lock Bar (Right Side only)
11- Front Fender
12- Lift Arm Cylinder
13- Lift Arm
14- Rear Work Light
15- Combination Lamp
(Turn signal / Hazard Light / Clearance
Light / Brake Light)
16- Muffler Tail Pipe
17- Hydraulic Oil Tank
18- Battery (One each onboth the right and
left sides)
19- Counterweight
20- Towing Pin
21- Fuel Filler Port
22- Radiator / Oil Cooler
NOTE: Illustrations on this page are those for
the typical model. They may appear
differently on other models.
