7-88
M4GB-07-104
(Right) (Wrong)
Front
M4GB-07-103
Rotate tires when uneven or abnormal wear is recognized on
either front or rear, or right and left tire. Tire rotation is recom-
mended to achieve uniformity of wear on tires or equalization
of tire service life.
• Switch tires only between the front and rear positions. Do
not switch the tires between diagonal positions.
• Align the tire rotation direction with the tire tread design
pattern. Especially traction tread design pattern (optional)
will affect not only economy of tire but also safety in op
-
eration.
Measure the groove depth at 1/4 tread width position
[shown with X mark (1) in the figure].
Use limit of the groove depth shall be approx. 85% of the new
tire groove depth. In case extreme uneven wear or exposed
rubbing strips are found, replace the tire even before reaching
85%.
Tread width
Groove depth
Tread width
