7-91
M4GB-07-106
M4GB-07-109
1. Remove the filter:
Remove screw (7) under cup holder (6) and tilt the cup
holder forward. While pushing circulation air filter (9)
downward, remove circulation air filter (9) from stoppers
(8).
2. Clean circulation air filter (5) using compressed air or by
washing with water. Washing procedure with water is as
follows:
2.1 Use tap water.
2.2 Submerge the filter in water containing a neutral deter
-
gent for about 5 minutes.
2.3 Clean the filter with water again.
2.4 Sufficiently dry the filter.
3. Install the cleaned circulation air filter or a new filter by
following the filter removal procedure described in step 1
in the reverse order.
