Hitachi ZW310 - Page 306


7-106
4. Propeller shaft mounting bolt
Model ZW180 ZW220 ZW250 ZW310
Bolt dia. mm 12 12 12 12
Quantity
20 20 20 20
M4GB-07-017
5. Propeller shaft support bearig mounting bolt
Model ZW180 ZW220 ZW250 ZW310
Bolt dia. mm
20 20 20 20
Quantity
2 2 2 2
M4GB-07-128
6. Transmission mounting bolt: Bracket
Model ZW180 ZW220 ZW250 ZW310
Bolt dia. mm
16 20 12 20 12 16
Quantity
8 4 8 4 8 8
M4GB-07-157 M4GB-07-130
ZW220, ZW250 ZW180, ZW310
