S-35
8. Turbocharger Cover in Engine
Compartment
•
Avoid skin contact with highly heated
parts such as the engine, muffler, etc.
immediately after operation of the
machine. Severe burns may result.
SSH4407874
ZW-0020
ZW180
ZW-0013
ZW220, ZW250
9. Bottoms at Both Right and Left Side Covers of Rear Frame
•
Sign indicartes a hazard of rotating parts, such as belt. Turn
off before inspection and maintenance.
10. Pipings for Oil Cooler
•
Avoid skin contact with highly heat-
ed parts such as the oil piping, etc.
immediately after operation of the
machine. Severe burns may result.
SS263G9-12601
ZW-0013
SS263G9-12121
ZW-0013
To Next Page
