Galaxy Dimension Installer Manual
5-10
Removing a MAX
3
Reader from the System
On-Line Mode
1. Access engineer mode.
2. Disconnect the MAX
3
reader (AB line and power).
3. Exit engineer mode.
4. The message 1 MOD. MISSING — [<],[>] to View is displayed.
5. Press the A or B key.
6. The message MAX XX —º =REMOVE MODULE is displayed.
7. Press the º key to acknowledge and accept that the MAX
3
reader has been removed. The keypad
returns to the unset banner.
Operating Instructions
The MAX
3
must be presented with a valid user card to allow access. Opening the door without presenting a
valid card activates a door forced alarm at the panel; the buzzer sounds and LED 2 flashes until the door is
closed.
Activating the egress switch allows the door to be opened without activating an alarm when no card has been
presented to the MAX
3
.
1. Ensure that LED 3 is on and all other LEDs are off.
2. Swipe the MAX with a standard user or nightlock access user card. LED 3 switches off and LED 2
switches on for the programmed Open Timeout.
3. Open the door while the LED 2 is on and access the area.
4. Close the door; LED 2 switches off and LED 3 switches on. The door must be closed within the pro-
grammed Close Timeout; if the door remains open longer than this, an alarm is activated.
Card-Held Function
The MAX
3
or DCM card can be assigned a single menu option (refer to option 42.1.8 = CODES.User
Codes.MAX Function). To activate the function assigned to the MAX
3
or DCM card, hold the card in front
of the reader for three seconds; all of the LEDs switch on. If a keypad has been assigned to the MAX func-
tion then it displays the details of this option. If no keypad is assigned, pressing a key on any of the keypads
assigned to a common group to the user displays the card-held function.
Card-Held System Setting
If the MAX
3
or DCM card is assigned one of the setting options (option 12, 13, 14 & 16 – 19), the card-held
functions starts the setting procedure for the groups assigned to the card.
NOTE: If Group Restriction is assigned, then only the groups that are common to both the MAX
3
reader
and the MAX
3
user are set/unset
To unset the system using the MAX
3
or DCM card, swipe the reader with a valid card. The reader beeps. All
of the groups assigned to the card are instantly unset.
Access Control (cont’d)
