Honeywell N4680 User Manual

N4680 2D Decoded Scan Engine User Guide 71
F4—Insert a character multiple times
Send “xx” character “nn” times in the output message, leaving the cursor in the cur-
rent position. Syntax = F4xxnn where xx stands for the insert character’s hex value
for its ASCII code, and nn is the numeric value (00-99) for the number of times it
should be sent. Refer to the ASCII Conversion Chart (Code Page 1252), beginning
on page 216 for decimal, hex and character codes.
E9 and F4 Example: Send all but the last characters, followed by 2 tabs
Send all characters except for the last 8 from the bar code above, followed by 2
tabs.
Command string: E908F40902
The data is output as: 1234567890AB <tab><tab>
BA—Insert a string
Send “ss” string of “nn” length in the output message, leaving the cursor in the cur-
rent position. Syntax = BAnnnns...s where nnnn stands for the length of the string,
and s...s stands for the string. The string is made up of hex values for the characters
in the string. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on
page 216 for decimal, hex and character codes.
B9 and BA Example: Look for the string “AB” and insert 2 asterisks (**)
Using the bar code above, send all characters up to but not including “AB.” Insert 2
asterisks at that point, and send the rest of the data with a carriage return after.
Command string: B900024142BA00022A2AF10D
E9 “Send all but the last characters” command
08 Number of characters at the end to ignore
F4 “Insert a character multiple times” command
09 Hex value for a horizontal tab
02 Number of times the tab character is sent
B9 “Send all characters up to a string” command
0002 Length of the string (2 characters)
41 Hex value for A
42 Hex value for B
BA “Insert a string” command
0002 Length of the string to be added (2 characters)
