NFS2-3030 Programming Manual — P/N 52545:A 11/29/2005 11
Introduction to the Control Panel General Information
1.4 Introduction to the Control Panel
The NFS2-3030 is an intelligent Fire Alarm Control Panel (FACP) with features suitable for most
applications.
There are two basic configuration options for the NFS2-3030. It can be ordered with:
• a front display/keypad, which allows programming and viewing options at the panel, or
• no display/keypad.
This manual gives programming instructions using the front display/keypad.
Displayless Mode
When there is no keypad/display at the panel, it is controlled by remote annunciators. VeriFire™
Tools programming is required. The displayless panel has four buttons on its circuit board that are
service-level switches for local operation should it become necessary. They are the only buttons,
and are clearly marked with ACK for Acknowledge, SIGSIL for Signal Silence, SYSRST for
System Reset, and LAMP TEST. These buttons are mainly for installer use: the operator should
utilize a remote annunciator for these functions, if possible. The status indicator LEDs on the
circuit board are the same as on the display/keypad; refer to the NFS2-3030 Operating Manual for
LED descriptions.
Refer to VeriFire™ Tools for information on programming without an NFS2-3030 display/keypad.
A PC is required when using VeriFire™.
Canadian applications must conform to ULC requirements for displays and network control. Refer
to the Canadian Applications appendix in this panel’s installation manual.
1.4.1 Features
Programming features include the following:
• Ease of use - Field program the control panel without special software skills.
DPI-232 Manual 51499
TM-4 Installation Document (Reverse Polarity Transmitter) 51490
UDACT Manual (Universal Digital Alarm Communicator/Transmitter) 50050
ACT-1 Installation Document 52527
ACT-2 Installation Document 51118
VEC 25/50 Manual 50686
RM-1 Series Remote Microphone Installation Document 51138
RA400Z Remote LED Annunciator Document I56-508
RFX Wireless Interface Manual 51012
UZC-256 Universal Zone Coder Manual 15216
UZC-256 Programming Manual 15976
XP Transponder Manual 15888
XP10-M Ten Input Monitor Module Installation Document I56-1803
XP5 Series Manual 50786
XP6-C Supervised Control Module Installation Document I56-1805
XP6-MA Six Zone Interface Module Installation Document I56-1806
XP6-R Six Relay Control Module Installation Document I56-1804
XPIQ Audio Transponder Manual 51013
Table 1.1 Related Documents (2 of 2)
