NFS2-3030 Programming Manual — P/N 52545:A 11/29/2005 39
Point Program Program
Figure 3.23 Holiday Menu Screen
The cursor will appear in the date fields, and may be moved using the keyboard arrow keys. Type to
add/edit any holiday dates.
Soft Keys
ANY YEAR: Press to place asterisks in the YY section of the field. An asterisk denotes any year.
NEXT/PREVIOUS SELECTION: Press to view the next or previous group of five holidays.
ACCEPT: Press to save changes to the date fields and to return to the Panel Program Menu.
3.4 Point Program
The Point Program menu allows the programmer to enter/change point information for detectors,
modules, and general, releasing, logic and trouble zones.
Press the Point Programming Menu soft key of the Program/Alter Status Menu to display the
screen below.
Figure 3.24 Point Program Menu
HOLIDAY MENU
MM/DD/YY
01 01/01/**
02 05/30/05
03 07/04/**
04 09/05/05
ANY YEAR 05 12/25/**
NEXT SELECTION ACCEPT
PREVIOUS SELECTION BACK
POINT PROGRAM MENU
POINT SELECT:
LyyDzzz (DETECTOR)
NEXT POINT ACCEPT
PREVIOUS POINT BACK
