50 NFS2-3030 Programming Manual — P/N 52545:A 11/29/2005
Program Point Program
Figure 3.35 Zone Point Programming Screen
Soft Keys
ZONE LABEL: Press to type in a 20-character maximum zone description that will appear in the
zone’s display messages.
ACCEPT: Press to save the message and return to the previous screen.
3.4.4 Releasing Zone
Releasing Zone Programming
This screen displays when a releasing zone is chosen at the Point Program menu (see Figure 3.24
on page 39).
Figure 3.36 Releasing Zone Programming Menu Screen
Refer to Appendix B, “Releasing Applications” for a full explanation of the fields below.
Soft Keys
DELAY TIME: Press this soft key to type a value from 0 to 60 (seconds). Default 00
ABORT SWITCH: Press this soft key to scroll through the selection list of ULI, IRI, NYC, or AHJ.
Default:ULI
ZONE POINT PROGRAMMING
Zyyy
ZONE LABEL:
ACCEPT
BACK
RELEASING ZONE PROGRAMMING MENU
ZR08
DELAY TIME: 00
ABORT SWITCH: ULI
CROSS ZONE: NO ACCEPT
SOAK TIME: 0000 BACK
To Next Page
