130 NFS2-3030 Programming Manual — P/N 52545:A 11/29/2005
Type Codes FlashScan Codes
G.5 FlashScan Codes
This section provides a list of FlashScan Codes for FlashScan SLC devices. Select from these codes
to define the type of point:
HORN CIRCUIT Y N Y NAC fire Supervised NAC
AUDIBLE CKT Y N Y NAC fire Supervised NAC
SPEAKER Y N Y NAC fire Supervised NAC for speaker circuits
blank Y N Y NAC n/a Supervised NAC for undefined device
NONRESET CTL N N N Relay or NAC n/a Supervised output, unaffected by “System Reset”
command
TELEPHONE N N N Relay fire Supervised Telephone circuit
CONTROL NAC Y N Y NAC fire Supervised NAC
ISOLATED NAC Y N Y NAC fire Supervised NAC for notification appliance, used
with audio isolators. Activates even if there is a short
on its NAC circuit. For ULC installations only.
ISOLATED SPK Y N Y NAC fire Supervised NAC for speaker circuits, used with
audio isolators. Activates even if there is a short on
its audio circuit. For ULC installations only.
GEN ALARM N Y Y NAC fire Control Module, XPC-8, or an XP5-C (in NAC mode)
configured as a Municpal Box Transmitter for NFPA
72 Auxiliary Fire Alarm Systems applications (MBT-
1 required). This Type ID can also be used for
general alarm activation.
GEN SUPERVIS N Y Y NAC supervisory Control Module, XPC-8, or an XP5-C (in NAC mode)
activated under any Supervisory condition (includes
sprinkler type).
GEN TROUBLE N Y Y NAC trouble Control Module, XPC-8, or an XP5-C (in NAC mode)
activated under any System Trouble condition.This
device will not turn ON when it is in trouble (short or
open).
GENERAL PEND N Y Y NAC trouble Control Module XPC-8 circuit, or an XP5-C (in NAC
mode) that will activate upon receipt of an alarm
and/or trouble condition, and remain in the ON state
until all events have been ACKNOWLEDGED. This
device will not turn ON when it is in trouble (short or
open)
TROUBLE PEND N Y Y NAC trouble Control Module or an XP5-C (in NAC mode) that will
activate upon receipt of a trouble condition, and
remain in the ON state until all troubles have been
ACKNOWLEDGED. This device will not turn ON
when it is in trouble (short or open).
ALARMS PEND N Y Y NAC fire Control module or NAC for output that will activate
upon receipt of an alarm condition, and remain in
the alarm state until all alarms have been
acknowledged.
INST RELEASE N Y N NAC (SLC only) fire Supervised for open circuits and ground faults.
Short = normal
REL. FORM C N Y N Form-C relay
(SLC only)
n/a Directs relay outputs to perform a releasing function.
RELEASE CKT N Y N NAC (SLC only) n/a Directs outputs to perform a releasing function.
REL CKT ULC N Y N NAC (SLC only) n/a Directs outputs to perform a release function as
required by ULC.
REL END BELL N Y N NAC n/a Activates NAC audio or visual device when
releasing circuits shut off.
REL AUDIBLE Y Y N NAC n/a Activates audio or visual devices steady when
releasing starts.
FORM C RESET N Y N Form-C Relay
(SLC only)
n/a Control module used to interrupt 24V power to four-
wire conventional detectors for 30 seconds upon
reset. Used in conjunction with a monitor module
with a conventional detector Type ID
* Values represent program defaults
Table G.3 SLC Control Module Type Codes (2 of 2)
Label Device/Point
FlashScan Codes
HEAT FST-751/R, FST-851/R
ION FSI-751, FSI-851
PHOTO FSP-751,FSD-751P/RP, FSP-851, FSD-751PL/RPL, FSH-751
BEAM FSB-200,FSB-200S
RFX SMOKE SDRF-751
Table G.4 FlashScan Codes (1 of 2)
