Appendix H: System Troubles
Table H.1 is a list of System Troubles that could occur during the course of FACP operation. The
System Trouble Name column is the text that displays in the system trouble message. The System
Trouble Index is the number associated with the trouble in FACP memory. It is the number that can
be used as an argument in a Trouble Equation.
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
0 GROUND FAULT 62 ANNUN 24 NO ANSWER 189 STYLE 6 NEG LOOP 8 251 NETWORK INCOMPATIBILITY
1 AC FAIL 63 ANNUN 25 TROUBLE 190 STYLE 6 NEG LOOP 9 252-383 RESERVED
2 BATTERY 64 ANNUN 25 NO ANSWER 191 STYLE 6 NEG LOOP 10 384 REMOTE DISPLAY 1 TROUBLE
3 STYLE 6 POS LOOP 1 65 ANNUN 26 TROUBLE 192 STYLE 6 POS LOOP 3 385 REMOTE DISPLAY 1 NO ANSWER
4 STYLE 6 POS LOOP 2 66 ANNUN 26 NO ANSWER 193 STYLE 6 POS LOOP 4 386 REMOTE DISPLAY 2 TROUBLE
5 CORRUPT LOGIC EQUAT 67 ANNUN 27 TROUBLE 194 STYLE 6 POS LOOP 5 387 REMOTE DISPLAY 2 NO ANSWER
6 RESERVED 68 ANNUN 27 NO ANSWER 195 STYLE 6 POS LOOP 6 388 REMOTE DISPLAY 3 TROUBLE
7 EPROM ERROR 69 ANNUN 28 TROUBLE 196 STYLE 6 POS LOOP 7 389 REMOTE DISPLAY 3 NO ANSWER
8 INTERNAL RAM ERROR 70 ANNUN 28 NO ANSWER 197 STYLE 6 POS LOOP 8 390 REMOTE DISPLAY 4 TROUBLE
9 EXTERNAL RAM ERROR 71 ANNUN 29 TROUBLE 198 STYLE 6 POS LOOP 9 391 REMOTE DISPLAY 4 NO ANSWER
10 PROGRAM CORRUPTED 72 ANNUN 29 NO ANSWER 199 STYLE 6 POS LOOP 10 392 REMOTE DISPLAY 5 TROUBLE
11 NO DEV INST ON L1 73 ANNUN 30 TROUBLE 200 RESERVED 393 REMOTE DISPLAY 5 NO ANSWER
12 PANEL DOOR OPEN 74 ANNUN 30 NO ANSWER 201 BUZZER OFF-LINE 394 REMOTE DISPLAY 6 TROUBLE
13 AUXILIARY TROUBLE 75 ANNUN 31 TROUBLE 202 RESERVED 395 REMOTE DISPLAY 6 NO ANSWER
14 RESERVED 76 ANNUN 31 NO ANSWER 203 RESERVED 396 REMOTE DISPLAY 7 TROUBLE
15 ANNUN 1 TROUBLE 77 ANNUN 32 TROUBLE 204 RESERVED 397 REMOTE DISPLAY 7 NO ANSWER
16 ANNUN 1 NO ANSWER 78 ANNUN 32 NO ANSWER 205 RESERVED 398 REMOTE DISPLAY 8 TROUBLE
17 ANNUN 2 TROUBLE 79 NETWORK FAIL PORT A 206 PRINTER PAPER OUT 399 REMOTE DISPLAY 8 NO ANSWER
18 ANNUN 2 NO ANSWER 80 NETWORK FAIL PORT B 207 PRINTER OFF LINE 400 REMOTE DISPLAY 9 TROUBLE
19 ANNUN 3 TROUBLE 81 NETWORK FAILURE 208 RESERVED 401 REMOTE DISPLAY 9 NO ANSWER
20 ANNUN 3 NO ANSWER 82 ADV WALK TEST 209 RESERVED 402 REMOTE DISPLAY 10 TROUBLE
21 ANNUN 4 TROUBLE 83 CHARGER FAIL 210 MANUAL MODE ENTERED 403 REMOTE DISPLAY 10 NO ANSWER
22 ANNUN 4 NO ANSWER 84 GROUND FAULT LOOP 2 211 NCM COMM LOSS 404 REMOTE DISPLAY 11 TROUBLE
23 ANNUN 5 TROUBLE 85 STYLE 6 NEG LOOP 1 212 STYLE 4 SHORT A LOOP 1 405 REMOTE DISPLAY 11 NO ANSWER
24 ANNUN 5 NO ANSWER 86 STYLE 6 NEG LOOP 2 213 STYLE 4 SHORT B LOOP 1 406 REMOTE DISPLAY 12 TROUBLE
25 ANNUN 6 TROUBLE 87 GROUND FAULT LOOP 1 214 STYLE 4 SHORT A LOOP 2 407 REMOTE DISPLAY 12 NO ANSWER
26 ANNUN 6 NO ANSWER 88 RESERVED 215 STYLE 4 SHORT B LOOP 2 408 REMOTE DISPLAY 13 TROUBLE
27 ANNUN 7 TROUBLE 89 RESERVED 216 STYLE 4 SHORT A LOOP 3 409 REMOTE DISPLAY 13 NO ANSWER
28 ANNUN 7 NO ANSWER 90 PROG MODE ACTIVATED 217 STYLE 4 SHORT B LOOP 3 410 REMOTE DISPLAY 14 TROUBLE
29 ANNUN 8 TROUBLE 91 LOADING...NO SERVICE 218 STYLE 4 SHORT A LOOP 4 411 REMOTE DISPLAY 14 NO ANSWER
30 ANNUN 8 NO ANSWER 92 BASIC WALK TEST 219 STYLE 4 SHORT B LOOP 4 412 REMOTE DISPLAY 15 TROUBLE
31 ANNUN 9 TROUBLE 93 NFPA 24HR REMINDER 220 STYLE 4 SHORT A LOOP 5 413 REMOTE DISPLAY 15 NO ANSWER
32 ANNUN 9 NO ANSWER 94 NVRAM BATT TROUBLE 221 STYLE 4 SHORT B LOOP 5 414 REMOTE DISPLAY 16 TROUBLE
33 ANNUN 10 TROUBLE 95 RESERVED 222 STYLE 4 SHORT A LOOP 6 415 REMOTE DISPLAY 16 NO ANSWER
34 ANNUN 10 NO ANSWER 96 RESERVED 223 STYLE 4 SHORT B LOOP 6 416 REMOTE DISPLAY 17 TROUBLE
35 ANNUN 11 TROUBLE 97 RESERVED 224 STYLE 4 SHORT A LOOP 7 417 REMOTE DISPLAY 17 NO ANSWER
36 ANNUN 11 NO ANSWER 98 RESERVED 225 STYLE 4 SHORT B LOOP 7 418 REMOTE DISPLAY 18 TROUBLE
37 ANNUN 12 TROUBLE 99 RESERVED 226 STYLE 4 SHORT A LOOP 8 419 REMOTE DISPLAY 18 NO ANSWER
38 ANNUN 12 NO ANSWER 100 RESERVED 227 STYLE 4 SHORT B LOOP 8 420 REMOTE DISPLAY 19 TROUBLE
39 ANNUN 13 TROUBLE 101 RESERVED 228 STYLE 4 SHORT A LOOP 9 421 REMOTE DISPLAY 19 NO ANSWER
40 ANNUN 13 NO ANSWER 102 RESERVED 229 STYLE 4 SHORT B LOOP 9 422 REMOTE DISPLAY 20 TROUBLE
41 ANNUN 14 TROUBLE 103 RESERVED 230 STYLE 4 SHORT A LOOP 10 423 REMOTE DISPLAY 20 NO ANSWER
42 ANNUN 14 NO ANSWER 104 RESERVED 231 STYLE 4 SHORT B LOOP 10 424 REMOTE DISPLAY 21 TROUBLE
43 ANNUN 15 TROUBLE 105 STYLE 6 ON LOOP 3 232 RESERVED 425 REMOTE DISPLAY 21 NO ANSWER
44 ANNUN 15 NO ANSWER 106 RESERVED 233 STYLE 6 SHORT LOOP 1 426 REMOTE DISPLAY 22 TROUBLE
45 ANNUN 16 TROUBLE 107 RESERVED 234 STYLE 6 SHORT LOOP 2 427 REMOTE DISPLAY 22 NO ANSWER
46 ANNUN 16 NO ANSWER 108 MAN EVAC INITIATED 235 STYLE 6 SHORT LOOP 3 428 REMOTE DISPLAY 23 TROUBLE
47 ANNUN 17 TROUBLE 109 MAN EVAC RECEIVED 236 STYLE 6 SHORT LOOP 4 429 REMOTE DISPLAY 23 NO ANSWER
48 ANNUN 17 NO ANSWER 110-175 RESERVED 237 STYLE 6 SHORT LOOP 5 430 REMOTE DISPLAY 24 TROUBLE
49 ANNUN 18 TROUBLE 176 GROUND FAULT LOOP 3 238 STYLE 6 SHORT LOOP 6 431 REMOTE DISPLAY 24 NO ANSWER
50 ANNUN 18 NO ANSWER 177 GROUND FAULT LOOP 4 239 STYLE 6 SHORT LOOP 7 432 REMOTE DISPLAY 25 TROUBLE
51 ANNUN 19 TROUBLE 178 GROUND FAULT LOOP 5 240 STYLE 6 SHORT LOOP 8 433 REMOTE DISPLAY 25 NO ANSWER
52 ANNUN 19 NO ANSWER 179 GROUND FAULT LOOP 6 241 STYLE 6 SHORT LOOP 9 434 REMOTE DISPLAY 26 TROUBLE
53 ANNUN 20 TROUBLE 180 GROUND FAULT LOOP 7 242 STYLE 6 SHORT LOOP 10 435 REMOTE DISPLAY 26 NO ANSWER
54 ANNUN 20 NO ANSWER 181 GROUND FAULT LOOP 8 243 NCM COM LOSS 436 REMOTE DISPLAY 27 TROUBLE
55 ANNUN 21 TROUBLE 182 GROUND FAULT LOOP 9 244 RESERVED 437 REMOTE DISPLAY 27 NO ANSWER
56 ANNUN 21 NO ANSWER 183 GROUND FAULT LOOP 10 245 RESERVED 438 REMOTE DISPLAY 28 TROUBLE
57 ANNUN 22 TROUBLE 184 STYLE 6 NEG LOOP 3 246 RESERVED 439 REMOTE DISPLAY 28 NO ANSWER
58 ANNUN 22 NO ANSWER 185 STYLE 6 NEG LOOP 4 247 RESERVED 440 REMOTE DISPLAY 29 TROUBLE
59 ANNUN 23 TROUBLE 186 STYLE 6 NEG LOOP 5 248 RESERVED 441 REMOTE DISPLAY 29 NO ANSWER
60 ANNUN 23 NO ANSWER 187 STYLE 6 NEG LOOP 6 249 RESERVED 442 REMOTE DISPLAY 30 TROUBLE
61 ANNUN 24 TROUBLE 188 STYLE 6 NEG LOOP 7 250 SELF TEST FAILED 443 REMOTE DISPLAY 30 NO ANSWER
Table H.1 System Trouble Names and Codes (1 of 2)
