NFS2-3030 Programming Manual — P/N 52545:A 11/29/2005 129
Type Codes for Output Devices Type Codes
G.4 Type Codes for Output Devices
This section provides a list of Type Codes for SLC control module points. Select from these codes
to define the type of point.
EQUIP MONITR non-alarm
security
N Y Used for monitoring equipment
SECURITY L security Y Y Indicates activation of security alarm
LATCH SUPERV supervisory Y Y Indicates latching supervisory condition
NC SUP L supervisory Y Y Indicates latching supervisory conditon, where an open
circuit=active. SLC only.
TRACK SUPERV supervisory N Y Monitors for waterflow tamper switches for alarm points
NC SUP T supervisory N Y Indicates tracking supervisory conditon, where an open
circuit=active. SLC only.
SPRINKLR SYS supervisory Y Y Monitors a waterflow device
SYS MONITOR security Y Y Monitors equipment security
TAMPER supervisory Y Y Indicates activation of tamper switch
ACK SWITCH non-alarm N N Emulates panel Acknowledge switch
ALLCALL PAGE non-alarm N Y Emulates AMG-1 All-call switch and telephone page
DRILL SWITCH
non-alarm
*
N N Emulates panel Drill switch, activates silenceable fire outputs
EVACUATE SWITCH non-alarm* N N Emulates panel Drill Switch, activates silenceable fire outputs
FIRE CONTROL non-alarm N Y Monitors non-fire activations
NON FIRE non-alarm N Y Monitors non-fire activations
NC NON FIRE non-alarm N Y Monitors non-fire activations, where an open circuit=active. SLC
only.
PAS INHIBIT non-alarm N N Inhibits Positive Alarm Sequence
POWER MONITR trouble
N N Monitors main and auxiliary power supplies (use trouble zones for
activations)
RESET SWITCH non-alarm N N Emulates keypad Reset switch
SIL SWITCH non alarm N N Emulates keypad Signal Silence switch
TELE PAGE non-alarm N Y Emulates Page Button on FFT-7. Allows remote paging to a fire
area
TROUBLE MON trouble N N Monitors trouble inputs (use trouble zones for activations)
Blank fire alarm Y Y Monitors for a device with no description
HEAT DETECT fire alarm Y Y Monitors for conventional heat detector
RF MON MODUL fire alarm Y Y Wireless alarm-monitoring device
RF PULL STA fire alarm Y Y Wireless manual fire-alarm-activating device
RF SUPERVSRY supervisory N Y Wireless supervisory-monitoring device
ABORT SWITCH non-alarm N Y Provides an abort function through a monitor module (connected to
a UL-listed abort station) for a releasing zone.
MAN RELEASE fire alarm
Y Y Provides a manual release through a monitor module (connected to
a UL-listed pull station) for a releasing zone
MAN REL DELAY fire alarm† Y Y Provides a manual release with a 10-second delay through a
monitor module (connected to a UL-listed pull station) for a
releasing zone
SECOND SHOT fire alarm† Y Y Provides a second manual release through a monitor module
(connected to a UL-listed pull station) for a releasing zone
* Local Mode treats this point as a fire alarm point.
Does not participate in Local Mode
Local Mode activation of NACs only. No releasing.
Point Characteristics
Type Code Point Type
Latching
(Y=yes
N=no)
Activates
CBE
Device Function
Table G.2 Type Codes for Monitor Modules (2 of 2)
Type Code
Silenceable
(Y=yes
N=no)*
Switch
Inhibit
(Y=yes,
N=No)
*
Walk Test
(Y=yes,
N=No)*
SLC Output Point
Local Mode
Group Point
Types
Device Function
CONTROL Y N Y NAC n/a Supervised NAC
RELAY Y N Y Relay n/a Relay output
BELL CIRCUIT Y N Y NAC fire Supervised NAC
STROBE CKT Y N Y NAC fire Supervised NAC
Table G.3 SLC Control Module Type Codes (1 of 2)
