NFS2-3030 Programming Manual — P/N 52545:A 11/29/2005 37
Panel Program Menu (2) Program
DETECTOR POLL: Press to select loop-polling mode. (See note below.)
MODULE POLL: Press to select loop-polling mode. (See note below.)
RAPID POLL: For CLIP mode only - enable or disable Rapid Poll for CLIP. This feature will poll
the first 20 modules more often to speed response on manual pull stations.
WIRING STYLE: Press to select the NFPA wiring style (4 or 6) of the loop. If Style 6 is entered
when the wiring is Style 4, a trouble message will be generated at the panel.
BLINK MODE: Press to enable (ON) or disable (OFF) detector LED blinking for this loop.
3.3.5 Custom Action Message
A Custom Action Message appears when the MORE INFORMATION soft key is pressed when an
event is displayed on the Event Counts screen. This panel supports up to 100 Custom Action
Messages.
Figure 3.21 Custom Action Message Screen
CUSTOM ACTION MESSAGE:Enter a number with a value of 001 to 100 to display the
corresponding Custom Action Message, or to add or edit a message.
MESSAGE: This soft key appears after VIEW is pressed. Press to enter/edit a custom message in
the four lines indicated. The message may be up to 160 characters.
VIEW: Press this soft key to view the message that corresponds to the number entered in the
underlined field.
NOTE: FlashScan and CLIP Mode
FlashScan devices can be programmed to run in either CLIP or FlashScan mode. The types can not
be mixed on a loop: for example, if Loop 1 is programmed with a FlashScan module poll, CLIP
modules may not be used on that loop.
A detector’s LEDs will light a steady green for several seconds while it is subjected to a detector test
during FlashScan polling. Each detector is tested this way on a regular basis. During the short time the
LEDs are on steady, the detector is not providing fire protection.
CUSTOM ACTION MESSAGE
CUSTOM ACTION MESSAGE: 001
MESSAGE
Edit
Custom
Action
Message here.
ACCEPT
VIEW BACK
