Program Panel Program Menu (2)
Figure 3.16 Weekly Occupancy Schedule Screen
Use the arrow keys on the keyboard to navigate between occupancy time fields: use the keypad to
type in the time values.
Soft Keys
WEEKLY OCCUPANCY SCHEDULE: Press this soft key to toggle between schedules 1 - 10. A
value of zero indicates no schedule.
ACCEPT: Press this to save changes made on the screen.
3.3.3 Remote Display Menu
This screen displays when the REMOTE DISPLAY MENU soft key is pressed at the Panel
Programming Menu 2 screen.
Figure 3.17 Remote Display Menu Screen
WEEKLY OCCUPANCY SCHEDULE
WEEKLY OCCUPANCY SCHEDULE: 10
SUNDAY - , -
MONDAY 08:00-12:00, 13:00-18:00
TUESDAY 08:00-12:00, 13:00-18:00
WEDNESDAY 08:00-12:00, 13:00-18:00
THURSDAY 08:00-12:00, 13:00-18:00
FRIDAY 08:00-12:00, 13:00-18:00
SATURDAY 08:00-12:00, -
HOLIDAY - , -
ACCEPT
BACK
NOTE: To change the language of the remote display, or to program the panel banner to appear in
the remote display, refer to Section 5.3.1, “LCD-160 Download Menu”, on page 79.
REMOTE DISPLAY MENU
D01:YES D02:NO D03:NO D04:NO
D05:NO D06:NO D07:NO D08:NO
D09:NO D10:NO D11:NO D12:NO
D13:NO D14:NO D15:NO D16:NO
D17:NO D18:NO D19:NO D20:NO
D21:NO D22:NO D23:NO D24:NO
D25:NO D26:NO D27:NO D28:NO
D29:NO D30:NO D31:NO D32:NO
INSTALL REMOTE DISPLAY
POINT PROGRAMMING BACK
To Next Page
