94 NFS2-3030 Programming Manual — P/N 52545:A 11/29/2005
Releasing Applications Abort Switches
Each Cross Zone option and the conditions required to activate releasing zone ZR01 are shown in
the table below, according to the example in Figure B.8.
B.3.6 Using Type Codes for Releasing Zones
The control panel provides a set of Type Codes designed for releasing applications for inputs and
outputs. This section details how to program each of these Type Codes.
Type Codes designed for releasing zone inputs (SLC monitor modules).
Type Codes designed for releasing zone outputs (SLC control modules).
Cross Zone
Selection (Cross=)
Condition(s) Required to Activate the Releasing zone
Cross=No An alarm from any initiating device activates the releasing zone.
Cross=Yes An alarm from any two initiating devices activates the releasing zone.
Cross=Zone
For example:
An alarm from two initiating devices mapped to different primary general zones, but
mapped to the same releasing zone.
• An alarm from L02D101 and L02D103
• An alarm from L02D102 and L02D104
• An alarm from L02D101 and L02D104
• An alarm from L02D102 and L02D103
The two detectors listed in each set above are each mapped to different primary
general zones, but both list ZR01 in their zone maps.
Cross=Heat Activation of heat detector L02D104 and one smoke detector (L02D101, L02D102,
or L02D103).
Type Code What the Type Code does Refer to
ABORT SWITCH
(tracking)
Provides an abort function through a
monitor module (connected to a UL-listed
abort station) for a releasing zone.
“How to Program an Abort Switch” on
page 95
MAN. RELEASE
(latching)
Provides a manual release through a
monitor module (connected to a UL-listed
pull station) for a releasing zone.
“How to Program a Manual Release
Switch” on page 96
MAN REL DELAY
(latching)
Provides a manual release with a
10-second delay through a monitor
module (connected to a UL-listed pull
station) for a releasing zone.
“How to Program a Manual Release
Delay Switch” on page 97
SECOND SHOT
(latching)
Provides a second manual release
through a monitor module (connected to a
UL-listed pull station) for a releasing zone.
“How to Program a Second Shot Switch”
on page 98
Type Code What the Type Code does Refer to
REL END BELL Activates an NAC audio or visual device
when releasing circuits shut off.
“How to Program a Release End Bell
Circuit” on page 99
REL CKT ULC Directs outputs to perform a release
function as required by ULC.
“How to Program a ULC Release Circuit”
on page 100
RELEASE CKT Directs outputs to perform a releasing
function.
“How to Program a Release Circuit” on
page 101
REL. FORM C Directs relay outputs to perform a
releasing function.
“How to Program a Release Form-C
Circuit” on page 102
REL AUDIBLE Activates audio or visual devices steady
when releasing starts.
“How to Program a Release Audible
Circuit” on page 103
INST RELEASE Activates non-releasing output (SLC
modules) with no delay time.
“How to Program an Instant Release
Circuit” on page 104
