134 NFS2-3030 Programming Manual — P/N 52545:A 11/29/2005
System Troubles
Table H.2 gives a description of each system trouble.
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
444 REMOTE DISPLAY 31
TROUBLE
522 RESERVED 547 RESERVED 572 GROUND FAULT PORT A
445 REMOTE DISPLAY 31 NO
ANSWER
523 RESERVED 548 RESERVED 573 GROUND FAULT PORT B
446 REMOTE DISPLAY 32
TROUBLE
524 RESERVED 549 RESERVED 574 AMPLIFIER TROUBLE
447 REMOTE DISPLAY 32 NO
ANSWER
525 RESERVED 550 RESERVED 575 AUXIN TROUBLE
448 SYSTEM INITIALIZATION 526 RESERVED 551 RESERVED 576 DIGIN TROUBLE
449-502 RESERVED 527 RESERVED 552 RESERVED 577 FFT TROUBLE
503 SOFTWARE MISMATCH 528 RESERVED 553 RESERVED 578 REMOTE MIC TROUBLE
504 NO POWER SUPPLY INST 529 RESERVED 554 RESERVED 579 DAP PORT A FAILURE
505 LOOP 1-2 COMM FAILURE 530 RESERVED 555 RESERVED 580 DAP PORT B FAILURE
506 LOOP 3-4 COMM FAILURE 531 RESERVED 556 RESERVED 581 DAA NO ANSWER
507 LOOP 5-6 COMM FAILURE 532 RESERVED 557 RESERVED 582 LOCAL MIC TROUBLE
508 LOOP 7-8 COMM FAILURE 533 RESERVED 558 RESERVED 583 LOCAL PHONE TROUBLE
509 LOOP 9-10 COMM FAILURE 534 RESERVED 559 RESERVED 584 ANALOG OUTPUT A
TROUBLE
510 TEST PROGRAM UPDATE 535 RESERVED 560 RESERVED 585 ANALOG OUTPUT B
TROUBLE
511 RESERVED 536 RESERVED 561 RESERVED 586 ANALOG OUTPUT C
TROUBLE
512 RESERVED 537 RESERVED 562 RESERVED 587 ANALOG OUTPUT D
TROUBLE
513 RESERVED 538 RESERVED 563 RESERVED 588 FLASH IMAGE ERROR
514 RESERVED 539 RESERVED 564 RESERVED 589 POWER SUPPLY TROUBLE
515 RESERVED 540 RESERVED 565 RESERVED
516 RESERVED 541 RESERVED 566 RESERVED
517 RESERVED 542 RESERVED 567 RESERVED
518 RESERVED 543 RESERVED 568 RESERVED
519 RESERVED 544 RESERVED 569 RESERVED
520 RESERVED 545 RESERVED 570 RESERVED
521 RESERVED 546 RESERVED 571 RESERVED
Table H.1 System Trouble Names and Codes (2 of 2)
SYSTEM TROUBLES
TROUBLE MESSAGE TYPE TROUBLE DESCRIPTION
AC FAIL Loss of AC power to DAA. Investigate whether there is an AC power loss, or whether the DAA-
PS is correctly installed and wired.
ADV WALK TEST There is an Advanced Walk Test in progress.
AMPLIFIER TROUBLE The DAA is in trouble. The ouput is overloaded or the amplifier is damaged. Remove outputs
to determine if the DAA was overloaded. If it still does not work, call Technical Services.
ANALOG OUTPUT x
TROUBLE A trouble has occurred on DVC-AO analog output x (1 - 4). The analog output is configured
for Style 7, but no audio signal is returned. Investigate and fix.
ANNUN x
NO ANSWER The annunciator at address x is not responding.
ANNUN x
TROUBLE The annunciator at address x is in trouble.
AUXILIARY TROUBLE Auxiliary device connected to the CPU2-3030 at J5 is in trouble or the cable is missing.
AUXIN TROUBLE Generated when the auxiliary input is supervised (as determined in VeriFire™ Tools
programming) and no signal is coming from the input. Check wiring and source.
BASIC WALK TEST A Basic Walk Test is in progress.
BATTERY The power supply’s battery voltage is too high or too low. Check the batteries for problems.
Replace batteries if necessary.
BUZZER OFF-LINE The piezo is disabled.
CHARGER FAIL The DAA’s battery charger is not functioning. Investigate and correct.
CORRUPT LOGIC EQUAT The database that houses the panel’s logic equations is corrupt. It must be re-downloaded, or
all programming must be cleared and re-entered.
DAA NO ANSWER A DAA is not responding. Investigate and fix.
Table H.2 System Trouble Descriptions (1 of 3)
