NFS2-3030 Programming Manual — P/N 52545:A 11/29/2005 53
Point Program Program
Add Point/ Zone
Figure 3.39 Add Logic Point/Zone Screen
The cursor will be present in the logic equation. Place it, using the arrow keys on the keyboard, at
the place where the additional point should be inserted.
Soft Keys
POINT SELECT: Press to scroll through the list of possible formats (detector, module, etc.). Stop
at the desired format. Type in the address for the additional point.
ACCEPT: Press to insert the point into the equation where the cursor is blinking, and to return to
the previous screen.
NEXT/PREVIOUS POINT: Press these soft keys to scroll forward or backward from the
displayed point to the next installed point.
Add Logic Function
This screen appears when the ADD LOGIC FUNCTION soft key is pressed at the Logic Zone
Programming Menu screen.
.
Figure 3.40 Add Logic Function Screen
The cursor will be present in the logic equation. Place it, using the arrow keys on the keyboard, at
the place where the logic function should be inserted.
LOGIC ZONE PROGRAMMING MENU
LOGIC ZONE ZLxxxx
AUTOMATIC OFF
AND(Z20,OR(L2D159,L2D14))
POINT SELECT:
L01D043 (DETECTOR)
NEXT POINT ACCEPT
PREVIOUS POINT BACK
LOGIC ZONE PROGRAMMING MENU
LOGIC ZONE ZLxxxx
AUTOMATIC OFF
AND(Z20,OR(L2D159,L2D14))
LOGIC FUNCTION: AND ACCEPT
BACK
To Next Page
