Page 88 Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
11 Use fault state value on
restart 4
Used when the input 4 is in the fault state at
restart
12 Use fault state value on
restart 5
Used when the input 5 is in the fault state at
restart
13 Use fault state value on
restart 6
Used when the input 6 is in the fault state at
restart
14 Use fault state value on
restart 7
Used when the input 7 is in the fault state at
restart
15 Use fault state value on
restart 8
Used when the input 8 is in the fault state at
restart
Parameter list
Table 25: MAO block parameters
ST_REV The revision level of the static data associated with the function block.
TAG_DESC The user description of the application of the block.
STRATEGY Used to identify grouping of blocks. This data is not checked or
processed by the block.
ALERT_KEY The identification number of the plant unit. This information may be
used in the host for sorting alarms, etc.
MODE_BLK The actual, target, permitted, and normal modes of the block. Target:
The mode to “go to”
Actual: The mode the “block is currently in”
Permitted: Allowed modes that target may take on
Normal: Most common mode for target
BLOCK_ERR This parameter reflects the error status associated with the hardware or
software components associated with a block. It is a bit string so that
multiple errors may be shown.
CHANNEL It is used for accessing LCD Transducer Block of RMA803 device.
IN_1 This is an input1 for the MAO function block.
IN_2 This is an input2 for the MAO function block.
IN_3 This is an input3 for the MAO function block.
IN_4 This is an input4 for the MAO function block
IN_5 This is an input5 for the MAO function block.
IN_6 This is an input6 for the MAO function block.
IN_7 This is an input7 for the MAO function block.
IN_8 This is an input8 for the MAO function block.
MO_OPTS This is an optional parameter for specifying output operations for the
MAO function block. It is mainly used for specifying values to be
transferred to LCD Transducer Block in fault state status.
