Page 106 Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
Troubleshooting the Integrator block
Table 31: Integrator block
Problem Cause Things to check Recommended Action
Integrator block mode
is in OOS and does
not change to AUTO
mode.
Read
MODE_BLOCK.PERMITTED.
Add AUTO mode to
MODE_BLOCK.PERMITTED.
Read
MODE_BLOCK.ACTUAL of
Resource block.
If necessary, set
MODE_BLOCK.TARGET to
AUTO.
NOTE:
If the mode is to OOS for
maintenance, then do not
change the mode to AUTO.
Schedule Block is not scheduled and
therefore cannot execute to go to
Target Mode. Schedule the block
to execute.
Check the License Status
parameter value of the block
Check whether License for
additional function blocks has
been purchased. Otherwise
purchase the license and then
upgrade.
Integrator block mode
is in OOS mode with
Block Configuration
Error.
Check INTEG_TYPE INTEG_TYPE must not be
zero/blank.
Check TIME_UNIT 1 and
TIME_UNIT 2.
TIME_UNIT1 & TIME_UNIT 2
must not be zero/blank.
Value of output does
not make sense.
Check TOTAL_SP. TOTAL_SP must be set to a
valid value and cannot be left at
0, if INTEG_TYPE is UP_AUTO,
DN_AUTO.
Value of output is
going in negative
value.
Check REV_FLOW1 and
REV_FLOW 2.
For forward flow REV_FLOW1
and REV_FLOW 2 must be set
as Forward, and for reverse flow
REV_FLOW1 & REV_FLOW 2
must be set as Reverse.
Check INTEG_OPTS
Flow forward and flow reverse
For forward flow in
INTEG_OPTS flow, forward must
be selected and for reverse flow
in INTEG_OPTS flow, reverse
must be selected.
Block alarms are not
reported.
Read FEATURE_SEL. Reports are not selected in
FEATURE_SEL. If features do
not include Reports, then the
host must poll for alarms.
Read LIM_NOTIFY. Set LIM_NOTIFY to a value
higher than zero, but not higher
than MAX_NOTIFY.
