Page 18 Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
The Advanced Display Menus
The Advanced Display menus are organized into three levels, as shown by Table 7. There is a
<Return> menu item at each level that allows the user to return to the previous level.
Table 7: Advanced Display Main Menu Structure
Level 1 Level 2 Level 3
<Exit>
n/a n/a
Diagnostics
Critical
Non-Critical
For details go to the Diagnostics Menu table.
Display Setup
LCD Contrast
Common Setup
Screen 1
Screen 2
…
Screen 8
For details go to the Display Setup Menu table.
Note that the Advanced Display supports the
configuration of up to 8 different screens.
Note that only LCD Contrast, Rotation time, and
Rotation Enable are editable parameters. Rest all are
read only.
Information
Display
Elec Module
Model
Options
For details go to the Information Menu table.
Table 8: Diagnostics Menu
All Diagnostics menu items are Read Only.
<Return> Return to the Level 1 menu
Critical
<Return>
Active Diags # #
Shows the number of Critical Diagnostics that
are currently active.
Elec. Module
OK
FAULT
FAULT: There is a problem with the
Electronics Fieldbus Communication Module.
Non-
Critical
<Return>
Active Diags # #
Shows the number of Non-Critical Diagnostics
that are currently active.
Supply Voltage
OK
LOW
HIGH
OK: Supply voltage is within the specification
limit
LOW: Supply voltage is below the low
specification limit
HIGH: Supply voltage is above the high
specification limit.
Elec Module Temp
OK
OVER TEMP
OVERTEMP: Electronics temperature is
greater than 85 Deg C
To Next Page
