Honeywell SmartLine RMA800 - Button Operation During Monitoring

Revision 4 Foundation Fieldbus RMA803 Remote Indicator User's Guide Page 27
PV Function Block
Mode
The Function Block Mode is only displayed for Foundation Fieldbus Remote
Indicators. The eight possible Modes are shown below.
OOS Out Of Service
Auto Automatic
Man Manual
Cas Cascade
RCas Remote Cascade
Rout Remote Output
IMan Initialization Manual
LO Local Override
Process Variable Tag User Configurable. This field has 14 characters
PV Units User Configurable. This field has 8 characters
Pressure:
inH2O
inHg
ftH2O
mmH2O
mmHg
psi
bar
mbar
gf/cm2
kgf/cm2
Pa
kPa
Torr
atm
inH2O
inH2O
mmH2O
Level:
m
ft
cm
in
mm
yd
km
mile
Temperature:
o
C
o
F
o
R
K
mV
ohm
Mass Flow:
kg/min
kg/h
lb/min
lb/h
Volumetric Flow:
CFM
gal/min
L/min
m3/h
Mgal/d
gal/h
L/h
Miscellaneous:
mA
%
pH
Bar Graph
The limits of the bar graph are user-configurable for each screen.
Trend graph The limits of the trend graph are user-configurable for each screen.
The amount of time visible on the Trend graph is also configurable.
Button operation during monitoring
When the operator screens are active on the Advanced Display, the Increment and Decrement
buttons (
 and ) can be used to move to the next or previous operator screen without waiting for the
rotation time to expire. Pressing the Enter button (
↵ ) will call up the Main Menu.
