Table 17: LCD parameters
Block FF Parameter
PID BLOCK (PID) SP
PV
OUT
IN
CAS_IN
BKCAL_IN
BKCAL_OUT
RCAS_IN
ROUT_IN
RCAS_OUT
ROUT_OUT
FF_VAL
TRK_VAL
ARITHMETIC FUNCTION BLOCK OUT
IN
IN_LO
IN_1
IN_2
IN_3
INTEGRATOR BLOCK OUT
IN_1
IN_2
SIGNAL CHARACTERIZER BLOCK OUT_1
OUT_2
IN_1
IN_2
INPUT SELECTOR BLOCK OUT
IN_1
IN_2
IN_3
IN_4
IN_5
