Revision 4 Foundation Fieldbus RMA803 Remote Indicator User's Guide Page 33
Block_ERR
Bit
Block Alarms Description
7 Output Failure Output Failure detected by this block/back
calculation input has a status of Bad or Device
Failure.
NOTE:
It is not applicable to the Remote Indicator.
8 Memory Failure A diagnostic algorithm has found a failure in
memory (includes all types) and the device is
still able to communicate that condition.
9 Lost Static data If the object’s static data is Bad, then the
object’s database is set to its default values.
10 Lost NV data The NV and static parameters are saved
periodically. This alarm occurs, if new data was
supposed to be saved to NV at the next NV
write cycle, but prevented the write due to
power failure.
11 Readback Check failed This indicates the readback of the actual
continuous valve or other actuator position in
transducer units has failed.
12 Device needs
maintenance now
A diagnostic algorithm has found an invalid
condition, but the device is still able to operate
and communicate. The NV memory has
reached the maximum number of reliable writes.
NOTE:
It is not applicable to the Remote Indicator.
13 Power-up The resource is performing its first normal
execution, after power was applied to the
device. It is not an error but generates an alarm
that says that normal operation was interrupted
and is now being restored.
NOTE:
It is not applicable to the Remote Indicator.
14 Out-of-Service The actual mode is OOS. No control function
blocks are being processed.
