Page 52 Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
Parameter Description
UNIT_TYPES Unit selection for screen process value. Appropriate units need
to be selected based on the configured parameter. If desired
units are not present, 'custom' may be selected. The
UNIT_TYPES is present in all the eight screens:
UNIT_TYPES_1, UNIT_TYPES_2, UNIT_TYPES_3,
UNIT_TYPES_4, UNIT_TYPES_5, UNIT_TYPES_6,
UNIT_TYPES_7 and UNIT_TYPES_8
CUSTOM_UNIT Character string to represent custom units. This value is used
when Unit type of 'custom' is selected. Size: 8 Characters. The
CUSTOM_UNIT is present in all the eight screens:
CUSTOM_UNIT_1, CUSTOM_UNIT_2, CUSTOM_UNIT_3, and
CUSTOM_UNIT_4.
CUSTOM_TAG Tag to be displayed for the screen. Length: 14 Characters. The
CUSTOM_TAG is present in all the eight screens:
CUSTOM_TAG_1, CUSTOM_TAG_2, CUSTOM_TAG_3,
CUSTOM_TAG_4, CUSTOM_TAG_5, CUSTOM_TAG_6,
CUSTOM_TAG_7 and CUSTOM_TAG_8.
DISPLAY_TEMPLATE Represents the display screen template. Possible Values:
a) PV: Regular PV value is displayed
b) PV and Trend: PV value followed by a Trend is shown on
the display
c) PV and Bargraph: PV value followed by a Bargraph is
shown on the display
d) None: Screen will not be seen.
The DISPLAY_TEMPLATE is present in all the eight screens:
DISPLAY_TEMPLATE_1, DISPLAY_TEMPLATE_2,
DISPLAY_TEMPLATE_3, DISPLAY_TEMPLATE_4,
DISPLAY_TEMPLATE_5, DISPLAY_TEMPLATE_6,
DISPLAY_TEMPLATE_7 and DISPLAY_TEMPLATE_8
DECIMALS Number of digits to display after the decimal point. Range: 0 - 3.
DECIMALS is present in all the eight screens: DECIMALS_1,
DECIMALS_2, DECIMALS_3, DECIMALS_4, DECIMALS_5,
DECIMALS_6, DECIMALS_7 and DECIMALS_8
TREND_DURATION Duration of a trend screen in hours. Its valid range is 1-24. The
TREND_DURATION is present in all the eight screens:
TREND_DURATION_1, TREND_DURATION_2,
TREND_DURATION_3, TREND_DURATION_4,
TREND_DURATION_5, TREND_DURATION_6,
TREND_DURATION_7 and TREND_DURATION_8.
PV_LOLIM PV low limit
PV_HILIM PV high limit
DISPLAY_MESSAGE
A message with a maximum of 64 characters that appears on the
advanced display of the Remote Indicator.
SCREEN_ROTATION Configurable screen rotation timing (4 to 30 sec).
