Configuration Record Sheet
5/00 UDC3300 Expanded Model: DC330E User Manual 99
Group
Prompt
Function
Prompt
Value or
Selection
Factory
Setting
OUT ALG
OUT ALG _________
CURRNT
4-20 RNG _________ 100PCT
OUT2 ALG _________
CURRNT
RLYSTATE _________ 1OF2ON
RLY TYPE _________
MECHAN
INPUT 1
IN1 TYPE _________ 0-10mV
XMITTER1 _________ LINEAR
ANALYT _________ NONE
IN1 HI _________ 1000
IN1 LO _________ 0
RATIO 1 _________ 1.00
BIAS IN1 _________ 0
FILTER 1 _________ 0
BURNOUT1 _________ NONE
EMISSIV1 _________ 0.00
INPUT 2
IN2 TYPE _________ 0-10mV
XMITTER2 _________ LINEAR
ANALYT _________ NONE
IN2 HI _________ 1000
IN2 LO _________ 0
RATIO 2 _________ 1.00
BIAS IN2 _________ 0
FILTER 2 _________ 0
BURNOUT2 _________ NONE
EMISSIV2 _________ 0.00
INPUT 3
IN3 TYPE _________ DISABL
XMITTER3 _________ LINEAR
IN3 HI _________ 1000
IN3 LO _________ 0
RATIO 3 _________ 1.00
BIAS 3 _________ 0
FILTER 3 _________ 0
CONTROL
PV SOURC _________ INP 1
PID SETS _________ 1 ONLY
SW VALUE _________ 0.00
LSP’S _________ 1 ONLY
RSP SRC _________ NONE
AUTOBIAS _________ DISABL
SP TRACK _________ NONE
PWR MODE _________ MANUAL
PWR OUT _________ LAST
SP HiLIM _________ 1000
SP LoLIM _________ 0
ACTION _________ REVRSE
OUT RATE _________ DISABL
Group
Prompt
Function
Prompt
Value or
Selection
Factory
Setting
PCT/M UP _________ 0
PCT/M DN _________ 0
OUTHiLIM _________ 100
OUTLoLIM _________ 0
I Hi LIM _________ 100.0
I Lo LIM _________ 0.0
DROPOFF _________ 0
DEADBAND _________ 1.0
OUT HYST _________ 0.5
FAILMODE _________ NO LAT
FAILSAFE _________ 0.0
MAN OUT _________ ––
AUTO OUT _________ ––
PBorGAIN _________ GAIN
MINorRPM _________ MIN
CONTROL2
PV2 SRC _________ INP 2
FORCE MA _________ DISABL
PID SETS _________ 1 ONLY
SW VALUE _________ 0.00
LSP'S _________ 1 ONLY
RSP SRC _________ NONE
AUTOBIAS _________ DISABL
SP TRACK _________ NONE
SP HiLIM _________ 1000
SP LoLIM _________ 0
ACTION _________ REVRSE
OUT RATE _________ DISABL
PCT/M UP _________ 0
PCT/M DN _________ 0
OUTHiLIM _________ 100
OUTLoLIM _________ 0
I Hi LIM _________ 100.0
I Lo LIM _________ 0.0
DROPOFF _________ 0
DEADBAND _________ 1.0
FAILMODE _________ NO LAT
FAILSAFE _________ 0.0
OPTIONS
AUX OUT
or
CUR OUT2
_________
_________
DISABL
DISABL
4mA VAL _________ 0.0
20mA VAL _________ 0
DIG IN 1 _________ NONE
DIG1 COM _________ DISABL
DIG IN 2 _________ NONE
DIG2 COM _________ DISABL
