Configuration Record Sheet
100 UDC3300 Expanded Model: DC330E User Manual 5/00
Group
Prompt
Function
Prompt
Value or
Selection
Factory
Setting
COM
ComSTATE _________ DISABL
Com ADDR _________ 0
ComADDR2 _________ 0
SHEDENAB _________ DOSABL
SHEDTIME _________ 0
PARITY _________ ODD
BAUD _________ 2400
DUPLEX _________ HALF
WS FLOAT _________ FP b
TX DELAY _________ 1
SHEDMODE _________ LAST
SHED SP _________ TO LSP
UNITS _________ PERCNT
CSP RATO _________ 1.0
CSP BIAS _________ 0
CSP2RATO _________ 1.0
CSP2BIAS _________ 0
LOOPBACK _________ DISABL
ALARMS
A1S1 VAL _________ 90
A1S2 VAL _________ 10
A2S1 VAL _________ 95
A2S2 VAL _________ 5
A1S1TYPE _________ NONE
A1S2TYPE _________ NONE
A2S1TYPE _________ NONE
A2S2TYPE _________ NONE
A1S1 H L _________ HIGH
A1S1 EV _________ --
A1S2 H L _________ LOW
A1S2 EV _________ --
A2S1 H L _________ HIGH
A2S1 EV _________ --
A2S2 H L _________ LOW
Group
Prompt
Function
Prompt
Value or
Selection
Factory
Setting
A2S2 EV _________ --
AL HYST _________ 0.1
ALM OUT1 _________ NO LAT
BLOCK _________ DISABL
DISPLAY
DECIMAL _________ XXXX
DECIMAL2 _________ XXXX
TEMPUNIT _________ NONE
PWR FREQ _________ 60 HZ
RATIO 2 _________ DISABL
LANGUAGE _________ ENGLIS
MAINTEN
TIME 1 _________ DISABL
TIME 2 _________ DISABL
TIME 3 _________ DISABL
COUNTER1 _________ DISABL
COUNTER2 _________ DISABL
COUNTER3 _________ DISABL
PASSWORD _________ 0
RESTYPE _________ NONE
