Honeywell UDC3300 User Manual

Configuration
5/00 UDC3300 Expanded Model: DC330E User Manual 31
Function
Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory
Setting
INP ALG1
Input 1 Algorithm
ATTENTION
All Input
Algorithms operate in
engineering units except
feedforward which
operates in percent of
output units.
PV or RSP source in the
Control Set Up group must
be set to IN AL1.
NONE MuDIV
W AVG MULT
F FWRD CARB A
FFWDMu CARB B
RELHUM CARB C
SUMMER CARB D
HI SEL FCC
LO SEL DEW PT
√MuDIV OXYGEN
√MULT
NONE
MATH K
Weighted Average Ratio or
K Constant for Math
Selections
0.001 to 1000 floating - -
CALC HI
Calculated Variable High
Scaling Factor for Input
Algorithm
–999. to 9999. floating
(in engineering units)
- -
CALC LO
Calculated Variable Low
Scaling Factor for Input
Algorithm
–999. to 9999. floating
(in engineering units)
- -
ALG1 INA
Input Algorithm 1
Input A Selection
INPUT 1 IN AL1
INPUT 2 IN AL2
LP1OUT INPUT 3
LP2OUT
- -
ALG1 INB
Input Algorithm 1
Input B Selection
INPUT 1 IN AL1
INPUT 2 IN AL2
LP1OUT INPUT 3
LP2OUT
- -
ALG1 INC
Input Algorithm 1
Input C Selection
NONE LP2OUT
INPUT 1 IN AL1
INPUT 2 IN AL2
LP1OUT INPUT 3
- -
PCO SEL
Percent Carbon Source
(Input 3 must be enabled)
DISABL
ONLINE
DISABL
PCT CO
Percent Carbon Monoxide 0.020 to 0.350 (fractional
percent of CO)
0.200
ATM PRES
Atmospheric Pressure
Compensation
590.0 to 760.0 (mm Hg) 760.0
ALG1BIAS
Input Algorithm 1 Bias -999 to 9999 floating (in
engineering units)
0.000
