LPCB approved S-Quad Sensor with VAD device STATES
# - factory default settings
Device
LPCB approved STATE Meets ~ EN54-7 : 2000, A1:2002, A2:2006
* EN54-5 : 2000, A1:2002
Dual Optical & Heat sensor variant - S4-711
(With VAD) S4-711-VAD-HPR
(With VAD) S4-711-VAD-LPW
(With VAD) S4-711-VAD-HPW
(With Speech) S4-711-V
(With VAD & Speech) S4-711-V-VAD-HPR
(With VAD & Speech) S4-711-V-VAD-HPW
(With Sounder) S4-771-S
STATE 0 #
STATE 5
STATE 8
Medium optical smoke ~ / Class A1 heat *
Medium optical smoke ~ / Class B heat *
Delayed medium optical smoke ~ / Class A1 heat*
Dual Optical, Heat & CO sensor variant- S4-901
(With Speech & VAD) S4-911-V-VAD-HPR
(With Speech & VAD) S4-911-V-VAD-HPW
STATE 0 #
STATE 9
Medium optical smoke ~ / Class A1 heat *
Class A1 heat *
Optical & Heat sensor variant - S4-710
(With Sounder) S4-770-S
STATE 0 # Medium optical smoke ~ / Class A1 heat*
Heat sensor variant - S4-720
(With Speech & VAD) S4-720-V-VAD-HPR
(With Speech & VAD) S4-720-V-VAD-HPW
(With Sounder) S4-780-S
STATE 0 #
STATE 5
Class A1 heat *
Class B heat *
Optical sensor - S4-715
State 0 # Medium optical smoke
All S-Quad range of sensor sounder devices meet EN54-17:2005 Input/Output devices plus EN54-18:2005 Short circuit isolation for use on the transmission path of fire detection and alarm systems.
Sounder tone - Meets the following tone settings: High tone ( Continuous 933Hz) & Alternate tone (High 933Hz for 0.25s / low 700Hz for 0.25s)
When an S-Quad sensor is configured to operate a non LPCB approved STATE then this will contravene the LPCB approval.
# - these standards are met when the sensor is operating LPCB approved STATES.
All the LPCB approved STATES applicable to S-Quad fire sensors are shown. The required STATE is configured during commissioning. On initial power-up of the system all the sensors operate in
STATE 0.
Note sensor STATES are not applicable for wireless sensors.
Commissioning instructions
14 4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms.
Product Approval and Standards
