Page #77 background imageLoading...
Page #77 background image
Beam sensor STATES
States verses distance
Sensor STATES Ideal range
minimum to maximum
4 or 5 2m to 30m
2 or 3 5m to 100m
0 or 1 12m to 100m
State Definition Application
State 0#
Default
detection
A fire is detected when there is a 50% (3dB) fall in signal level, however if the fall is by 90% (10dB) in less than
1second and is maintained for 40 seconds, then a fault is registered. This allows the Control panel to differentiate
between a fire and a fault signal caused by accidental obscuration.
State 1 Normal
sensitivity
A fire is detected when there is a 50% (3dB) fall in signal level, however if the fall is by 90% (10dB) in less than
1 second and is maintained for 40 seconds then a fire is registered.
State 2 Medium
Sensitivity
A fire is detected when there is a 25% (1.3dB) fall in signal level, however if the fall is by 90% (10dB) in less than
1 second and is maintained for 40 seconds then a fault is registered.
State 3
Medium
Sensitivity
A fire is detected when there is a 25% (1.3dB) fall in signal level, however if the fall is by 90% (10dB) in less than
1 second and is maintained for 40 seconds then a fire is registered.
State 4 High Sensitivity
A fire is detected when there is a 10% (0.5dB) fall in signal level, however if the fall is by 90% (10dB) in less than
1 second and is maintained for 40 seconds then a fault is registered.
State 5 High Sensitivity
A fire is detected when there is a 10% (0.5dB) fall in signal level, however if the fall is by 90% (10dB) in less than
1 second and is maintained for 40 seconds then a fire is also registered.
State 15 No detection. This is a total disablement of the sensor.
# - factory default STATE
4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms. 77
Vigilon 4/6 loops & Compact (VA) panels & network nodes
